A Three.JS extension module for webgpu

[ ] - benchmarks [ ] - karaoke [ ] - NeRF [ ] - Zed 2i [ ] - Spatial Machine Learning Demo for https:// www.kaggle.com/competitions/blood-vessel-segmentation [] - blog roomba+ [] - video screenshot gif using pupeteer.js https://vitejs.dev/guide/migration.html https://vitejs.dev/guide/ssr.html https://v4.vitejs.dev/guide/ssr.html https://v4.vitejs.dev/guide/dep-pre-bundling.html https://apps.amandaghassaei.com/gpu-io/examples/wave2d/ react-native

NERF coming soon

simple-gpu simplifies WebGPU programming by removing as much shared state as it can get away with. To do this, it replaces the WebGPU API with two fundamental abstractions, resources and commands:

• A resource is a handle to a GPU resident object, like a texture, FBO or buffer.
• A command is a complete representation of the WebGPU state required to perform some draw call.

To define a command you specify a mixture of static and dynamic data for the object. Once this is done, simple-gpu takes this description and then compiles it into optimized JavaScript code. For example, here is a simple simple-gpu program to draw a triangle:

// importing the webgpu module creates a full screen canvas and
// WebGPU context, and then uses this context to initialize a new webgpu instance
const webgpu = require('simple-gpu')

// Calling simplewebgpu.init() creates a new partially evaluated draw command
const drawTriangle = webgpu.init({

  // Shaders in simplewebgpu. are just strings.  You can use glslify or whatever you want
  // to define them.  No need to manually create shader objects.
  frag: `
    precision mediump float;
    uniform vec4 color;
    void main() {
      gl_FragColor = color;
    }`,

  vert: `
    precision mediump float;
    attribute vec2 position;
    void main() {
      gl_Position = vec4(position, 0, 1);
    }`,

  // Here we define the vertex attributes for the above shader
  attributes: {
    // simplewebgpu.buffer creates a new array buffer object
    position: webgpu.buffer([
      [-2, -2],   // no need to flatten nested arrays, simpleWebgpu automatically
      [4, -2],    // unrolls them into a typedarray (default Float32)
      [4,  4]
    ])
    // simpleWebgpu automatically infers sane defaults for the vertex attribute pointers
  },

  uniforms: {
    // This defines the color of the triangle to be a dynamic variable
    color: webgpu.prop('color')
  },

  // This tells simpleWebgpu the number of vertices to draw in this command
  count: 3
})

// webgpu.frame() wraps requestAnimationFrame and also handles viewport changes
webgpu.frame(({time}) => {
  // clear contents of the drawing buffer
  webgpu.clear({
    color: [0, 0, 0, 0],
    depth: 1
  })

  // draw a triangle using the command defined above
  drawTriangle({
    color: [
      Math.cos(time * 0.001),
      Math.sin(time * 0.0008),
      Math.cos(time * 0.003),
      1
    ]
  })
})

See this example live

Check out the gallery. The source code of all the gallery examples can be found here.

simple-gpu has no dependencies, so setting it up is pretty easy. There are 3 basic ways to do this:

just use observablehq.com and

require('simple-gpu')

The easiest way to use simple-gpu in a project is via npm. Once you have node set up, you can install and use simple-gpu in your project using the following command:

npm i -S simple-gpu

For more info on how to use npm, check out the official docs.

If you are using npm, you may also want to try vite which is a live development server.

By default if you compile simple-gpu with vite then all error messages and run time checks are removed. This is done to reduce the size of the final bundle. If you are developing an application, you should run browserify using the --debug flag in order to enable error messages. This will also generate source maps which make reading the source code of your application easier.

You can also use simple-gpu as a standalone script if you are really stubborn. The most recent versions can be found in the dist/ folder and is also available from npm cdn in both minified and unminified versions.

• Unminified: https://npmcdn.com/simple-gpu/dist/simple-gpu.js
• Minified: https://npmcdn.com/simple-gpu/dist/simple-gpu.min.js

There are some difference when using simple-gpu in standalone. Because script tags don't assume any sort of module system, the standalone scripts inject a global constructor function which is equivalent to the module.exports of simple-gpu:

For vanilla HTML in modern browsers, import D3 from jsDelivr:

<!DOCTYPE html>
<html>
  <head>
    <meta content="width=device-width, initial-scale=1.0, maximum-scale=1.0, user-scalable=0" name="viewport" />
    <meta charset=utf-8>
  </head>
  <body>
  </body>
  <script language="javascript" type="module">
  import webgpu from "https://cdn.jsdelivr.net/npm/simple-gpu/+esm";
    let webgpu = webgpu.init()

    webgpu.frame(function () {
      webgpu.clear({
        color: [0, 0, 0, 1]
      })
    })
  </script>
</html>

simple-gpu just removes shared state and boilerplate from WebGPU. You can do anything you could in regular WebGPU with little overhead and way less debugging. simple-gpu emphasizes the following values:

• Simplicity The interface is concise and emphasizes separation of concerns. Removing shared state helps localize the effects and interactions of code, making it easier to reason about.
• Performance simple-gpu uses partial evaluation to remove almost all overhead.
• Minimalism simple-gpu just wraps WebGPU. It is not a game engine and doesn't have opinions about scene graphs or vector math libraries. Any feature in WebGPU is accessible, including advanced extensions like TODO
• Stability simple-gpu takes interface compatibility and semantic versioning seriously, making it well suited for long lived applications that must be supported for months or years down the road. It also has no dependencies limiting exposure to risky or unplanned updates.

In order to prevent performance regressions, simple-gpu is continuously benchmarked. You can run benchmarks locally using npm run bench or These measurements were taken using our custom scripts bench-history and bench-graph. You can read more about them in the development guide.

simple-gpu is still under active developement, and anyone willing to contribute is very much welcome to do so. Right now, what we need the most is for people to write examples and demos with the framework. This will allow us to find bugs and deficiencies in the API. We have a list of examples we would like to be implemented here, but you are of course welcome to come up with your own examples. To add an example to our gallery of examples, please send us a pull request!

simple-gpu has extensive API documentation. You can browse the docs online here.

The latest changes in simple-gpu can be found in the CHANGELOG.

For info on how to build and test headless, see the contributing guide here

All code (c) 2022 BSD License

TODO

Many examples use creative commons or public domain artwork for illustrative purposes. These assets are not included in any of the redistributable packages of simple-gpu.

• Peppers test image for cube comparison is public domain
• Test video (doggie-chromakey.ogv) by L0ckergn0me, used under creative commons license
• Cube maps (posx.jpeg, negx.jpeg, posy.jpeg, negy.jpeg, posz.jpeg, negz.jpeg) by Humus, used under creative commons 3 license
• Environment map of Oregon (ogd-oregon-360.jpg) due to Max Ogden (@maxogd on GitHub)
• DDS test images (alpine_cliff_a, alpine_cliff_a_norm, alpine_cliff_a_spec) taken from the CC0 license 0-AD texture pack by Wildfire games
• Tile set for tile mapping demo (tiles.png) from CC0 licensed cobblestone paths pack
• Audio track for audio.js example is "Bamboo Cactus" by 8bitpeoples. CC BY-ND-NC 1.0 license
• Matcap (spheretexture.jpg) by Ben Simonds. CC 3 license.
• Normal map (normaltexture.jpg) by rubberduck. CC0 license.

when developing locally, use npm run dev - change the module import from

  import webgpu from "https://cdn.jsdelivr.net/npm/simple-gpu/+esm";

to import simpleWebGpu from

  import webgpu from "../lib/main";

• [] glass of water
• [] PBR demo
• [] matrix multiply demo https://milhidaka.github.io/webgpu-blas/ https://gpu.rocks/#/
• [] write docs on auto-create bindgroups
• [] always render to a renderTarget not canvas because more composable
• mixins
• [] https://github.com/mattatz/THREE.Watercolor
• [] sentiment analysis

npm run dev
