A Tensorflow 2.x based implementation of
- Enhanced Deep Residual Networks for Single Image Super-Resolution (EDSR), winner of the NTIRE 2017 super-resolution challenge.
- Wide Activation for Efficient and Accurate Image Super-Resolution (WDSR), winner of the NTIRE 2018 super-resolution challenge (realistic tracks).
- Photo-Realistic Single Image Super-Resolution Using a Generative Adversarial Network (SRGAN).
This is a complete re-write of the old Keras/Tensorflow 1.x based implementation available here. Some parts are still work in progress but you can already train models as described in the papers via a high-level training API. Furthermore, you can also fine-tune EDSR and WDSR models in an SRGAN context. Training and usage examples are given in the notebooks
A DIV2K data provider automatically downloads DIV2K
training and validation images of given scale (2, 3, 4 or 8) and downgrade operator ("bicubic", "unknown", "mild" or
"difficult").
Important: if you want to evaluate the pre-trained models with a dataset other than DIV2K please read this comment (and replies) first.
Create a new conda environment with
conda env create -f environment.yml
and activate it with
conda activate sisr
You can find an introduction to single-image super-resolution in this article. It also demonstrates how EDSR and WDSR models can be fine-tuned with SRGAN (see also this section).
Examples in this section require following pre-trained weights for running (see also example notebooks):
- weights-edsr-16-x4.tar.gz
- EDSR x4 baseline as described in the EDSR paper: 16 residual blocks, 64 filters, 1.52M parameters.
- PSNR on DIV2K validation set = 28.89 dB (images 801 - 900, 6 + 4 pixel border included).
- weights-wdsr-b-32-x4.tar.gz
- WDSR B x4 custom model: 32 residual blocks, 32 filters, expansion factor 6, 0.62M parameters.
- PSNR on DIV2K validation set = 28.91 dB (images 801 - 900, 6 + 4 pixel border included).
- weights-srgan.tar.gz
- SRGAN as described in the SRGAN paper: 1.55M parameters, trained with VGG54 content loss.
After download, extract them in the root folder of the project with
tar xvfz weights-<...>.tar.gz
from model import resolve_single
from model.edsr import edsr
from utils import load_image, plot_sample
model = edsr(scale=4, num_res_blocks=16)
model.load_weights('weights/edsr-16-x4/weights.h5')
lr = load_image('demo/0851x4-crop.png')
sr = resolve_single(model, lr)
plot_sample(lr, sr)
from model.wdsr import wdsr_b
model = wdsr_b(scale=4, num_res_blocks=32)
model.load_weights('weights/wdsr-b-32-x4/weights.h5')
lr = load_image('demo/0829x4-crop.png')
sr = resolve_single(model, lr)
plot_sample(lr, sr)
Weight normalization in WDSR models is implemented with the new WeightNormalization layer wrapper of
Tensorflow Addons. In its latest version, this wrapper seems to
corrupt weights when running model.predict(...). A workaround is to set model.run_eagerly = True or
compile the model with model.compile(loss='mae') in advance. This issue doesn't arise when calling the
model directly with model(...) though. To be further investigated ...
from model.srgan import generator
model = generator()
model.load_weights('weights/srgan/gan_generator.h5')
lr = load_image('demo/0869x4-crop.png')
sr = resolve_single(model, lr)
plot_sample(lr, sr)
For training and validation on DIV2K images, applications should use the
provided DIV2K data loader. It automatically downloads DIV2K images to .div2k directory and converts them to a
different format for faster loading.
from data import DIV2K
train_loader = DIV2K(scale=4, # 2, 3, 4 or 8
downgrade='bicubic', # 'bicubic', 'unknown', 'mild' or 'difficult'
subset='train') # Training dataset are images 001 - 800
# Create a tf.data.Dataset
train_ds = train_loader.dataset(batch_size=16, # batch size as described in the EDSR and WDSR papers
random_transform=True, # random crop, flip, rotate as described in the EDSR paper
repeat_count=None) # repeat iterating over training images indefinitely
# Iterate over LR/HR image pairs
for lr, hr in train_ds:
# .... Crop size in HR images is 96x96.
from data import DIV2K
valid_loader = DIV2K(scale=4, # 2, 3, 4 or 8
downgrade='bicubic', # 'bicubic', 'unknown', 'mild' or 'difficult'
subset='valid') # Validation dataset are images 801 - 900
# Create a tf.data.Dataset
valid_ds = valid_loader.dataset(batch_size=1, # use batch size of 1 as DIV2K images have different size
random_transform=False, # use DIV2K images in original size
repeat_count=1) # 1 epoch
# Iterate over LR/HR image pairs
for lr, hr in valid_ds:
# .... The following training examples use the training and validation datasets described earlier. The high-level training API is designed around steps (= minibatch updates) rather than epochs to better match the descriptions in the papers.
from model.edsr import edsr
from train import EdsrTrainer
# Create a training context for an EDSR x4 model with 16
# residual blocks.
trainer = EdsrTrainer(model=edsr(scale=4, num_res_blocks=16),
checkpoint_dir=f'.ckpt/edsr-16-x4')
# Train EDSR model for 300,000 steps and evaluate model
# every 1000 steps on the first 10 images of the DIV2K
# validation set. Save a checkpoint only if evaluation
# PSNR has improved.
trainer.train(train_ds,
valid_ds.take(10),
steps=300000,
evaluate_every=1000,
save_best_only=True)
# Restore from checkpoint with highest PSNR.
trainer.restore()
# Evaluate model on full validation set.
psnr = trainer.evaluate(valid_ds)
print(f'PSNR = {psnr.numpy():3f}')
# Save weights to separate location.
trainer.model.save_weights('weights/edsr-16-x4/weights.h5') Interrupting training and restarting it again resumes from the latest saved checkpoint. The trained Keras model can be
accessed with trainer.model.
from model.wdsr import wdsr_b
from train import WdsrTrainer
# Create a training context for a WDSR B x4 model with 32
# residual blocks.
trainer = WdsrTrainer(model=wdsr_b(scale=4, num_res_blocks=32),
checkpoint_dir=f'.ckpt/wdsr-b-8-x4')
# Train WDSR B model for 300,000 steps and evaluate model
# every 1000 steps on the first 10 images of the DIV2K
# validation set. Save a checkpoint only if evaluation
# PSNR has improved.
trainer.train(train_ds,
valid_ds.take(10),
steps=300000,
evaluate_every=1000,
save_best_only=True)
# Restore from checkpoint with highest PSNR.
trainer.restore()
# Evaluate model on full validation set.
psnr = trainer.evaluate(valid_ds)
print(f'PSNR = {psnr.numpy():3f}')
# Save weights to separate location.
trainer.model.save_weights('weights/wdsr-b-32-x4/weights.h5')from model.srgan import generator
from train import SrganGeneratorTrainer
# Create a training context for the generator (SRResNet) alone.
pre_trainer = SrganGeneratorTrainer(model=generator(), checkpoint_dir=f'.ckpt/pre_generator')
# Pre-train the generator with 1,000,000 steps (100,000 works fine too).
pre_trainer.train(train_ds, valid_ds.take(10), steps=1000000, evaluate_every=1000)
# Save weights of pre-trained generator (needed for fine-tuning with GAN).
pre_trainer.model.save_weights('weights/srgan/pre_generator.h5')from model.srgan import generator, discriminator
from train import SrganTrainer
# Create a new generator and init it with pre-trained weights.
gan_generator = generator()
gan_generator.load_weights('weights/srgan/pre_generator.h5')
# Create a training context for the GAN (generator + discriminator).
gan_trainer = SrganTrainer(generator=gan_generator, discriminator=discriminator())
# Train the GAN with 200,000 steps.
gan_trainer.train(train_ds, steps=200000)
# Save weights of generator and discriminator.
gan_trainer.generator.save_weights('weights/srgan/gan_generator.h5')
gan_trainer.discriminator.save_weights('weights/srgan/gan_discriminator.h5')It is also possible to fine-tune EDSR and WDSR x4 models with SRGAN. They can be used as drop-in replacement for the original SRGAN generator. More details in this article.
# Create EDSR generator and init with pre-trained weights
generator = edsr(scale=4, num_res_blocks=16)
generator.load_weights('weights/edsr-16-x4/weights.h5')
# Fine-tune EDSR model via SRGAN training.
gan_trainer = SrganTrainer(generator=generator, discriminator=discriminator())
gan_trainer.train(train_ds, steps=200000)# Create WDSR B generator and init with pre-trained weights
generator = wdsr_b(scale=4, num_res_blocks=32)
generator.load_weights('weights/wdsr-b-16-32/weights.h5')
# Fine-tune WDSR B model via SRGAN training.
gan_trainer = SrganTrainer(generator=generator, discriminator=discriminator())
gan_trainer.train(train_ds, steps=200000)
