This cargo extension handles all the environment configuration needed for successfully building libraries
for Android from a Rust codebase, with support for generating the correct jniLibs directory structure.
cargo install cargo-ndk
You'll also need to install all the toolchains you intend to use. Simplest way is with the following:
rustup target add \
aarch64-linux-android \
armv7-linux-androideabi \
x86_64-linux-android \
i686-linux-android
Modify as necessary for your use case.
If you have installed the NDK with Android Studio to its default location, cargo ndk will automatically detect
the most recent NDK version and use it. This can be overriden by specifying the path to the NDK root directory in
the ANDROID_NDK_HOME environment variable.
cargo ndk -t armeabi-v7a -t arm64-v8a -o ./jniLibs build --release
This specifies the Android targets to be built (ordinary triples are also supported), the output directory to use for placing the .so files in the layout
expected by Android, and then the ordinary flags to be passed to cargo.
Create a build.rs in your project with the following:
use std::{env, path::{Path, PathBuf}};
fn main() {
if env::var("CARGO_CFG_TARGET_OS").unwrap() == "android" {
android();
}
}
fn android() {
println!("cargo:rustc-link-lib=c++_shared");
if let Ok(output_path) = env::var("CARGO_NDK_OUTPUT_PATH") {
let sysroot_libs_path =
PathBuf::from(env::var_os("CARGO_NDK_SYSROOT_LIBS_PATH").unwrap());
let lib_path = sysroot_libs_path.join("libc++_shared.so");
std::fs::copy(
lib_path,
Path::new(&output_path)
.join(&env::var("CARGO_NDK_ANDROID_TARGET").unwrap())
.join("libc++_shared.so"),
)
.unwrap();
}
}Add -v or -vv as you ordinarily would after the cargo command.
cargo-ndk derives which environment variables to read the same way as the cc crate.
These environment variables are exported for use in build scripts and other downstream use cases:
CARGO_NDK_ANDROID_PLATFORM: the Android platform API number as an integer (e.g.21)CARGO_NDK_ANDROID_TARGET: the Android name for the build target (e.g.armeabi-v7a)CARGO_NDK_OUTPUT_PATH: the output path as specified with the-oflagCARGO_NDK_SYSROOT_PATH: path to the sysroot inside the Android NDKCARGO_NDK_SYSROOT_TARGET: the target name for the files inside the sysroot (differs slightly from the standard LLVM triples)CARGO_NDK_SYSROOT_LIBS_PATH: path to the libraries inside the sysroot with the given sysroot target (e.g.$CARGO_NDK_SYSROOT_PATH/usr/lib/$CARGO_NDK_SYSROOT_TARGET)
Sometimes you just want the environment variables that cargo-ndk configures so you can, say, set up rust-analyzer in VS Code or similar.
If you want to source it into your bash environment:
source <(cargo ndk-env)
PowerShell:
cargo ndk-env --powershell | Out-String | Invoke-Expression
Rust Analyzer and anything else with JSON-based environment handling:
For configuring rust-analyzer, add the --json flag and paste the blob into the relevant place in the config.
- Linux
- macOS (
x86_64andarm64) - Windows
git clone and then install the crate with cargo:
cargo install --path .- cargo-cocoapods - for building .a files for all Apple platforms, and bundling for CocoaPods
This project is licensed under either of
- Apache License, Version 2.0 (LICENSE-APACHE or http://www.apache.org/licenses/LICENSE-2.0)
- MIT license (LICENSE-MIT or http://opensource.org/licenses/MIT)
at your option.
